Oracle Kernel Components
The kernel components relate to the background processes, buffer cache and shared pool and managing the resources without conflicts and corruptions requires special handling.
In RAC as more than one instance is accessing the resource, the instances require better coordination at the resource management level. Each node will have its own set of buffers but will be able to request and receive data blocks currently held in another instance’s cache. The management of data sharing and exchange is done by the Global Cache Services (GCS).
All the resources in the cluster group form a central repository called the Global Resource Directory (GRD), which is distributed. Each instance masters some set of resources and together all instances form the GRD. The resources are equally distributed among the nodes based on their weight.
The GRD is managed by two services called Global Caches Services (GCS) and Global Enqueue Services (GES), together they form and manage the GRD. When a node leaves the cluster, the GRD portion of that instance needs to be redistributed to the surviving nodes, a similar action is performed when a new node joins.
RAC Background Processes
Each node has its own background processes and memory structures, there are additional processes than the norm to manage the shared resources, theses additional processes maintain cache coherency across the nodes.
Cache coherency is the technique of keeping multiple copies of a buffer consistent between different Oracle instances on different nodes. Global cache management ensures that access to a master copy of a data block in one buffer cache is coordinated with the copy of the block in another buffer cache.
The sequence of a operation would go as below
1. When instance A needs a block of data to modify, it reads the bock from disk, before reading it must inform the GCS (DLM). GCS keeps track of the lock status of the data block by keeping an exclusive lock on it on behalf of instance A
2. Now instance B wants to modify that same data block, it to must inform GCS, GCS will then request instance A to release the lock, thus GCS ensures that instance B gets the latest version of the data block (including instance A modifications) and then exclusively locks it on instance B behalf.
3. At any one point in time,only one instance has the current copy of the block, thus keeping the integrity of the block.
GCS maintains data coherency and coordination by keeping track of all lock status of each block that can be read/written to by any nodes in the RAC. GCS is an in memory database that contains information about current locks on blocks and instances waiting to acquire locks. This is known as Parallel Cache Management(PCM).
The Global Resource Manager (GRM) helps to coordinate and communicate the lock requests from Oracle processes between instances in the RAC. Each instance has a buffer cache in its SGA, to ensure that each RAC instance obtains the block that it needs to satisfy a query or transaction. RAC uses two processes the GCS and GES which maintain records of lock status of each data file and each cached block using a GRD.
GCS maintains data coherency and coordination by keeping track of all lock status of each block that can be read/written to by any nodes in the RAC. GCS is an in memory database that contains information about current locks on blocks and instances waiting to acquire locks.
This is known as Parallel Cache Management(PCM). The Global Resource Manager (GRM) helps to coordinate and communicate the lock requests from Oracle processes between instances in the RAC. Each instance has a buffer cache in its SGA, to ensure that each RAC instance obtains the block that it needs to satisfy a query or transaction.
RAC uses two processes the GCS and GES which maintain records of lock status of each data file and each cached block using a GRD.
So what is a resource, it is an identifiable entity, it basically has a name or a reference, it can be a area in memory, a disk file or an abstract entity. A resource can be owned or locked in various states (exclusive or shared). Any shared resource is lockable and if it is not shared no access conflict will occur.
A global resource is a resource that is visible to all the nodes within the cluster. Data buffer cache blocks are the most obvious and most heavily global resource, transaction enqueue’s and database data structures are other examples. GCS handle data buffer cache blocks and GES handle all the non-data block resources.
All caches in the SGA are either global or local, dictionary and buffer caches are global, large and java pool buffer caches are local. Cache fusion is used to read the data buffer cache from another instance instead of getting the block from disk, thus cache fusion moves current copies of data blocks between instances (hence why you need a fast private network), GCS manages the block transfers between the instances.
